TOA
TOA M-61S T Microphone Input with Compressor
- SKU:
- M-61S T
- MPN:
- M-61S T
- Availability:
- In Stock Products Ship Warehouse Direct From Chicago IL
Frequently bought together:
Description
For Balanced, Low Impedance Microphones.High and Low Cut Fileters for tone control, 4.2k Hz and 330 Hz, 6 dB/octave. Phantom Power, +22V DC for condenser-type microphones. Activate by default, cut Jumper J1 to disable. Compressor Function Helps Prevent Overload And Distortion, activates when the module's input signal exceeds a preset, adjustable threshold. Compression Ratio: 2:1 (fixed), reduces the module's output signal level to 1 dB for every 2 dB increase in input siganl level. Threshold Control - turn CW to lower threshold (to activate compressor function with lower input signal) and CCW to increase threshold (to activate compressor function with higher input signal). Connector: removable terminal block
