TOA N-8000DI IP intercom Direct select interface unit,

32 relay outputs (N/O,500mA, 24 VDC) and (32) LED for the relay status indication, (32) non-voltage make contact inputs for direct select switch inputs

The N-8000DI is a Direct select unit designed for use with TOA's packet intercom system (IP network-compatible intercom system) that employs the packet audio technology. It is equipped with each 32 contact inputs and outputs, and the indicators on the front panel indicate the output statuses. Connecting the unit to the LAN permits the calling station display, external equipment control, and direct selection function to be realized. It can be mounted in an EIA equipment rack (1U size) with the use of an accessory rack mounting bracket or installed on a wall using an optional wall mounting bracket.,
